Severe weather conditions in the winter result in greater wear and other problems. To minimize the problems of winter driving, you should follow these suggestions:
ICM (Integrated Circuit Module) Relay Box: Schematic Diagrams
Schematic Diagram
...
Rear Wiper Motor: Repair procedures
Inspection
Rear Wiper Motor
1.
Remove the 4P connector from the rear wiper motor.
2.
Connect battery positive (+) and negative (-) cables to terminals 2 and 1 respectively.
3.
Check that ...
