Third generation SL (2010–2016) / Kia Sportage SL Service & Repair Manual / Engine Electrical System / Cruise Control System / Cruise Control Switch: Schematic Diagrams

Troubleshooting

Trouble Symptom Charts Trouble Symptom 1 Trouble Symptom 2 Trouble symptomProbable causeRemedyThe set vehicle speed varies greatly upward or downward"Surging" (repeated alternating accelerati ...

Cruise Control Switch: Repair procedures

Removal and Installation 1. Disconnect the battery (-) terminal. Tightening torque: Without battery sensor : 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft) With battery sensor : 4.0 ~ 6.0N ...

Other Information:

Schematic Diagrams
Circuit Diagram - ESC(1) Circuit Diagram - ESC(2) Circuit Diagram - ESC(3) ESC connector input/output Connector TerminalSpecificationRemarkNoDescription29IGNITION1(+)High level of wake up vol ...
