ESC Control Module: Repair procedures
Removal
1.
Turn the ignition switch OFF.
2.
Disconnect the brake tubes from the HECU by unlocking the nuts counterclockwise with a spanner.
Tightening torque :
12.7 ~ 16.7N.m(1.3 ~ 1.7kgf. ...
ESC Control Module: Components and Components Location
Components
1. Front - left tube2. Rear - right tube3. Rear - left tube4. Front - right tube5. MC26. MC17. ESC control module(HECU)8. Damper9. Bracket
...
